TDS – OEM’s Package

TDS - Online Dryout System - OEM's Package

Technology

Technology is of Online Dryout process for drying out wet transformer in energized conditions by monitoring the percentage of Moisture in the insulation to its Dry Weight. PTss TDS equipment is fitted with TIMES (Transformer Insulation Moisture Estimation System which automatically estimates the %M/DWi (%Moisture to Dry Weight of insulation) and triggers itself for self removal of moisture in Transformers. It uses Specialized cartridges for maintaining the %M/DWi to acceptable levels. This equipment is capable of being safely operated on transformers/reactors under energized conditions and is capable of being installed upto 764 KV Class. Process will not deteriorate any of the Oil characteristics before and after the process.

Process

PTss-TDS is basically designed to operate on an energized Transformer to remove moisture from it. The moisture is removed by circulation of Oil through TDS which has special type of absorptive cartridges which absorb and remove moisture from the oil. This process does not employ any heating or vacuum process of oil thereby retaining the original virgin characteristics of the oil. Process does not remove Oxidation inhibitors or fault gases. Equipment estimates the %M/Dwi (Percentage of Moisture to Dry Wt of Insulation) and automatically triggers itself for operation and is safe for unattended operation.

Capacity

TDS Series with flow rate of 300LPH with 4/6 Cartridges required per change out.

Power Requirements

3 phase, 415 Volts, 50 Hz 1 Hp is standard and other options available on specific request.

Dimension and Weight of equipment

Dimension(LxBxH): 1040 x 500 x 1600 mm.

Weight: 350 Kgs (Net) and 450 Kgs with Packed accessories.

Communication Details

Compatible to external interfaces provided include Ethernet (RJ45), MODBUS & IEC 61850 for SCADA communication as well IIOT & Web Browser for Data visualization as optional.

TDS – OEM
TDS – OEM
TDS OEM 3
TDS OEM 4
TDS OEM 5
TDS OEM 6
TDS – OEM's Package – Cartridge Series

Descriptions

Technology

Technology is of Online Dryout process for drying out wet transformer in energized conditions by monitoring the percentage of Moisture in the insulation to its Dry Weight. PTss TDS equipment is fitted with TIMES (Transformer Insulation Moisture Estimation System which automatically estimates the %M/DWi (%Moisture to Dry Weight of insulation) and triggers itself for self removal of moisture in Transformers. It uses Specialized cartridges for maintaining the %M/DWi to acceptable levels. This equipment is capable of being safely operated on transformers/reactors under energized conditions and is capable of being installed upto 764 KV Class. Process will not deteriorate any of the Oil characteristics before and after the process.

Process

PTss-TDS is basically designed to operate on an energized Transformer to remove moisture from it. The moisture is removed by circulation of Oil through TDS which has special type of absorptive cartridges which absorb and remove moisture from the oil. This process does not employ any heating or vacuum process of oil thereby retaining the original virgin characteristics of the oil. Process does not remove Oxidation inhibitors or fault gases. Equipment estimates the %M/Dwi (Percentage of Moisture to Dry Wt of Insulation) and automatically triggers itself for operation and is safe for unattended operation.

Specifications

Capacity

TDS Series with flow rate of 300LPH with 4/6 Cartridges required per change out.

Power Requirements

3 phase, 415 Volts, 50 Hz 1 Hp is standard and other options available on specific request.

Dimension and Weight of equipment

Dimension(LxBxH): 1040 x 500 x 1600 mm.

Weight: 350 Kgs (Net) and 450 Kgs with Packed accessories.

Communication Details

Compatible to external interfaces provided include Ethernet (RJ45), MODBUS & IEC 61850 for SCADA communication as well IIOT & Web Browser for Data visualization as optional.

TDS – OEM
TDS – OEM
TDS OEM 3
TDS OEM 4
TDS OEM 5
TDS OEM 6
